Inverters
10.2KW DUAL MPPT , DUAL A/C OUTPUT, 48V, Pure sine-wave On/Off grid STAND ALONE Inverter
6 KW LOW FREQUENCY, TRANSFORMER Inverter with DUAL AC-outputs, Wifi compatible, Parallel
Sacolar - WiFi compatible- 6KVA / 6KW Pure Sine Wave Axpert Type 48V Inverter / 2xMPPT (500 VOC High Voltage) / Parallel
5.5 KW High Voltage MPPT Inverter, 500 Voc, 48 V Pure Sine wave, WIFI Compatible
Sacolar - WiFi compatible- 5KVA / 5KW Pure Sine Wave Axpert Type 48V Inverter / 100A High Voltage MPPT / Parallel
Sacolar - WiFi compatible- 5KVA / 5KW Pure Sine Wave Axpert Type 48V Inverter / 80A Low Voltage MPPT / Parallel
Inverters change DC current from batteries or solar panels to 220V 50Hz alternating current (AC) as needed for appliances. The generated AC output is in a pure sine wave form that is identical to the grid AC.
The Axpert-type inverters are considered to be hybrid inverters because they can charge batteries from the grid (Eskom/Generator) and from solar panels.
|
Model |
5kVA/4kW 80A |
5kVA/5kW 80A PLUS |
5kVA/5kW 80A VICTOR |
5kVA/5kW 80A Sacolar |
5.5kVA/5.5kW VM-II |
|
Parallel capability |
Yes, 9 units |
Yes, 9 units |
No |
Yes, 6 units |
No |
|
INPUT |
|||||
|
Voltage |
230 VAC |
||||
|
Selectable voltage range |
170-280 VAC (for personal computers) |
||||
|
|
90-280 VAC (for home appliances) |
||||
|
Frequency range |
50 Hz/60 Hz (auto sensing) |
||||
|
OUTPUT |
|||||
|
AC voltage regulation (Batt. Mode) |
230 VAC± 5% |
||||
|
Surge Power |
10 000 VA |
11 000 VA |
|||
|
Efficiency (Peak) |
93% |
95% |
93.5 % |
||
|
Transfer time |
10 ms (for personal computers), 30ms for parallel configurations |
||||
|
|
20 ms (for home appliances) , 30ms for parallel configurations |
||||
|
Waveform |
Pure sine wave |
||||
|
BATTERY & AC CHARGER |
|||||
|
Battery voltage |
48 VDC |
||||
|
Floating & charge voltage |
Can be set |
||||
|
Overcharge protection |
60 VDC |
||||
|
Maximum charge current |
80 A |
60A (AC Charger) 140A (Solar + AC) |
80A (AC Charger) 100A (Solar + AC) |
||
|
Operate without batteries |
No |
Yes, if PV voltage > 150V |
No |
Yes, if PV voltage > 150V |
|
|
SOLAR CHARGER |
|||||
|
Maximum PV array power |
4400 W |
5500 W |
|||
|
MPPT range @ operating voltage |
60 VDC - 115 VDC |
120 - 450 VDC |
60 VDC - 115 VDC |
120 VDC – 450 VDC |
|
|
Maximum PV array open-circuit voltage |
145 VDC |
450 VDC |
145 VDC |
450 VDC |
|
|
Maximum charging current |
80A |
100A |
|||
|
Maximum efficiency |
98% |
||||
|
Standby power consumption |
2 W |
||||
|
PHYSICAL |
|||||
|
Dimension, D x W x H (mm) |
140 x 295 x 540 |
100 x 300 x 400 |
455 x 295 x 130 |
100 x 300 x 440 |
|
|
Net weight (kg) |
13.5 |
9.7 |
11.5 |
10 |
|
|
OPERATING ENVIRONMENT |
|||||
|
Humidity |
5 to 95 % Relative humidity (non-condensing) |
||||
|
Operating temperature |
0°C to 55°C |
-10°C to 50°C |
|||
|
Storage temperature |
-15°C to 60°C |
||||
